Mugin EV460 Full Electric Carbon Fiber UAV Platform

$9,999.00

We always listen to what our customers say. Some users of EV350 are asking for more payload than that of EV350. here it comes the EV460. The payload can be up to 8kg.

Mugin EV460 is a new full electric VTOL with a wingspan of 4600mm. The airframe is made of full carbon fiber which is lighter and more durable than other airframes that made of fiberglass or composite materials.

The same to EV350, this new VTOL features the quick-detach design which is easy to assemble and disasemble. It also features in the aerodynamic design of landing gear. The airframe comes with only 3 landing feet, save the space and weight, but still very stable while taking off or landing.

Specifications:

  • Wingspan: 4600mm
  • Length: 2180mm
  • Height: 690mm
  • Empty Weight: 15kg
  • Maximum Take-off Weight: 40kg
  • Cruise Speed: Max. 20m/s
  • Maximum Speed: 30m/s
  • Stall Speed: 16m/s
  • Maximum Flight Endurance: 2 Hours 45 minutes
  • Flight Range: 180km
  • Maximum Payload: 10kg
  • Battery type: 60000mah 12S (Not included)
  • Wind Resistance: grade 6
Categories: , Tags: , , , , ,

Description



We always listen to what our customers say. Some users of EV350 are asking for more payload than that of EV350, so here it comes the EV460 which payload can be up to 8kg.

Mugin EV460 is a new full electric VTOL with a wingspan of 4600mm. The airframe is made of full carbon fiber which is lighter and more durable than other airframes that made of fiberglass or composite materials.

The same to EV350, this new VTOL features the quick-detach design which is easy to assemble and disassemble. It also features in the aerodynamic design of landing gear. The airframe comes with only 3 landing feet, save the space and weight, but still very stable while taking off or landing.

Specifications:

  • Wingspan: 4600mm
  • Length: 2180mm
  • Height: 690mm
  • Empty Weight: 15kg
  • Maximum Take-off Weight: 40kg
  • Cruise Speed: Max. 20m/s
  • Maximum Speed: 30m/s
  • Stall Speed: 16m/s
  • Maximum Flight Time: 2 Hours 45 minutes
  • Flight Range: 180km
  • Payload: 10kg (35 minutes endurance with a 12s 30000mAh battery). 8kg (2 hours endurance)
  • Battery type: 60000mah 12S (Not included)
  • Wind Resistance: grade 6

Recommended Flight & Propulsion System: Click Here

Recommended setup (Not included, Extra Charged) – US$9399:

  • CUAV X7+ Pro Autopilot x 1
  • CUAV C-RTK 9Ps Positioning Module x 2
  • Eaglepower GA8025 175KV Motor x 1
  • T-motor Flame 180A ESC x 1
  • JXF 24″ Wooden Propeller x 1
  • T-motor V807 170KV x 4
  • T-motor Flame 180A ESC x 4
  • T-motor 28″ Propeller x 4
  • Savox SC-1256TG Servo x 4
  • Savox SV-1250MG Servo x 2
  • Savox SC-1256TG Servo x 2
  • Long UAV Pitot Tube x 1
  • CUAV Airspeed Sensor x 1
  • UAV Navigation Lights x 1 set
  • Build Kit x 1
  •

    •
